RFEM 5 | Result Lines for Internal Forces Analysis

In the model, there are two governing internal forces, Vz and My. In the printout report selection, I have only activated these two internal forces using the "Extreme Values" option. Why are the result lines under "Members – Internal Forces" displayed twice in the printout report?

Answer:

The reason for four result lines in this case is that for each selected internal force, a minimum as well as a maximum is output, including the associated remaining internal forces.

FAQ|004253
EN-US | Flag FAQ
[EN] FAQ 004253 | In the model, there are two governing internal forces, V-z and M-y. In the ...
Printout Report: Members - Internal Forces
Printout Report: Members - Internal Forces
  • First line: Numerical maximum of Vz (3.54 kN) with the corresponding internal forces
  • Second line: Numerical minimum of Vz (0 kN) with the corresponding internal forces
  • Third line: Numerical maximum of My(0 kNm) with the corresponding internal forces
  • Fourth line: Numerical minimum of My(-12.37 kNm) with the corresponding internal forces
