This model demonstrates the design of a steel rectangular tank without stiffeners. The structure includes overlapped sections to ensure stability and performance. The model provides insights into efficient steel tank construction methodologies, focusing on material usage without additional reinforcements.
Steel Rectangular Tank Construction Without Stiffener
| Block parameters editable dynamically | |
| Number of Nodes | 12 |
| Number of Lines | 16 |
| Number of Members | 0 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 12.364 tons |
| Dimensions (Metric) | 5.500 x 3.000 x 4.500 m |
| Dimensions (Imperial) | 18.04 x 9.84 x 14.76 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
