Steel Rectangular Tank without Stiffener and with Overlap
Steel rectangular tank design without stiffeners, showing overlap construction elements.
This image depicts a steel rectangular tank, constructed without stiffeners, displaying overlap in its construction elements. The overlap provides extra support to the tank structure. This method can enhance the tank's stability and durability in practical applications. The tank is designed to hold specific materials or liquids while maintaining structural integrity.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 12 |
| Number of Lines | 16 |
| Number of Members | 0 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 12.364 tons |
| Dimensions (Metric) | 5.500 x 3.000 x 4.500 m |
| Dimensions (Imperial) | 18.04 x 9.84 x 14.76 feet |
