This model features anticlastic shells, utilizing inputs such as the number of sides for a supporting polygon, with the option of five or more sides, along with its length and height. The anticlastic shape provides unique architectural and structural advantages, offering tension and compression balancing characteristics. This methodology is pivotal in designs requiring enhanced stability and dynamic aesthetics.


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Anticlastic Shells with Polygonal Support

Block parameters editable dynamically
Number of Nodes 26
Number of Lines 45
Number of Members 0
Number of Surfaces 20
Number of Solids 0
Number of Load Cases 1
Number of Load Combinations 0
Number of Result Combinations 0
Total Weight 245.738 tons
Dimensions (Metric) 30.777 x 9.000 x 32.361 m
Dimensions (Imperial) 100.97 x 29.53 x 106.17 feet

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
