The model features a semi-cylindrical barrel vault reinforced with a horizontal stiffener. The structural geometry is defined by specifying either the height or radius, allowing accurate design and load assessment. This setup is ideal for examining the effects of lateral support on the overall stability of the vault structure.
Barrel Vault with Horizontal Stiffener
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 10 |
| Number of Members | 0 |
| Number of Surfaces | 3 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 8.549 tons |
| Dimensions (Metric) | 4.800 x 1.200 x 6.000 m |
| Dimensions (Imperial) | 15.75 x 3.94 x 19.69 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
