Dlubal Material or Cross-Section Library as Grasshopper Component

Is the Dlubal material or cross-section library implemented as a Grasshopper component?


Answer:

RFEM has an extensive material and cross-section library. We made the conscious decision not to implement the entire library as a Grasshopper component, as this would require a component with thousands of entries and a large amount of data.

You can create your own component with the required materials and cross-sections using a value list. To do this, copy the complete Dlubal material and cross-section names into a Value List.

You can then save it as a "User Object" and used it as a fixed component in Grasshopper.

The FAQ video shows an example of creating a material and a cross-section component for RFEM 6.
