This model features anticlastic shell structures formed with straight-edged hypar surfaces, showcasing five hypar surfaces over a rectangular plan. Anticlastic surfaces in this context refer to saddle-shaped forms that convey architectural elegance and structural efficiency. The design exemplifies innovative space definition using straight-edged surfaces, creating dynamic and visually appealing structures.
Anticlastic Hypar Surfaces Over Rectangular Plan
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 68.002 tons |
| Dimensions (Metric) | 20.000 x 6.000 x 20.000 m |
| Dimensions (Imperial) | 65.62 x 19.69 x 65.62 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
