This model represents a reversed truncated pyramid soil structure, which can be defined either by specifying an angle or an offset. The model serves as an example of complex geometric configurations within soil structures, suitable for specialized simulations and analyses.
Reversed Truncated Pyramid Soil
| Block parameters editable dynamically | |
| Number of Nodes | 10 |
| Number of Lines | 14 |
| Number of Members | 0 |
| Number of Surfaces | 6 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 134.228 tons |
| Dimensions (Metric) | 6.072 x 2.000 x 7.072 m |
| Dimensions (Imperial) | 19.92 x 6.56 x 23.2 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
