Membrane Arch Structure
A membrane arch structure under a blue sky, providing a flexible, modern architectural solution.
A membrane arch structure can be seen against a clear blue sky. The structure consists of curved, supporting elements spanned by a flexible membrane. This type of structure provides an innovative solution to modern, aesthetic, and functional requirements in the building industry. The membrane allows for a wide span without additional support pillars. Such a structure is particularly suitable for temporary or semi-permanent applications.
Used in
3D Model
Specifications
| Number of Nodes | 120 |
| Number of Lines | 218 |
| Number of Members | 18 |
| Number of Surfaces | 103 |
| Number of Solids | 2 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 2 |
| Number of Result Combinations | 0 |
| Total Weight | 0.023 t |
| Dimensions (Metric) | 3.900 x 1.920 x 1.400 m |
| Dimensions (Imperial) | 12.8 x 6.3 x 4.59 feet |
