Barrel Vault Geometry with Variable Radius
Geometry of a barrel vault with a semi-cylindrical form, variable radius at ends, depicted via height and radius measurements.
The image depicts a semi-cylindrical barrel vault with variable radius at the ends. The geometry is detailed through height and radius measurements, illustrating the variations in curvature. This structural form is often used for architectural purposes due to its aesthetic appeal. The complexity of the design requires precise calculations to ensure stability and load distribution.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 4 |
| Number of Lines | 4 |
| Number of Members | 0 |
| Number of Surfaces | 1 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 5.421 tons |
| Dimensions (Metric) | 4.000 x 1.500 x 6.000 m |
| Dimensions (Imperial) | 13.12 x 4.92 x 19.69 feet |
