Column Base of Steel Roof in RFEM
3D RFEM model of a column base for the steel roof structure, including the base plate, steel column, and gusset plates.
The image shows a 3D model of a column base for the steel roof structure in RFEM. It displays the steel column, the base plate, the lateral gusset plates, and the anchor points. The model serves as the basis for the structural analysis and design of the column base.
Used in
3D Model
Specifications
| Number of Nodes | 2121 |
| Number of Lines | 3158 |
| Number of Members | 1304 |
| Number of Surfaces | 242 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 1 |
| Total Weight | 0.278 t |
| Dimensions (Metric) | 0.610 x 0.630 x 0.610 m |
| Dimensions (Imperial) | 2 x 2.07 x 2 feet |
