Shear Wall Model with Geometry, Structural System, and Material Properties
3D model of a shear wall with a display of the structural system, the dimensions (250 mm x 3600 mm), and the materials used: C20/25 concrete and B500S(C) reinforcing steel.
Display of a shear wall model with a total height of 13,500 mm and a width of 250 mm. The structural system shows the longitudinal and shear reinforcement for element R_M1 250/3600. The definition includes the material properties for C20/25 concrete according to EN 1992-1-1:2004/A1:2014, as well as B500S(C) reinforcing steel according to the same standard.
