Typical Beam-Column Bolted Connection

Technical drawing of a typical beam-column bolted connection showing an IPE300 beam connected to an HE340M column with detailed dimensions and plate thicknesses.

The technical drawing illustrates a typical bolted beam-column connection. An IPE300 beam is connected to a vertical HE340M column. The total column height is 1200 mm, divided into three segments of 400 mm each.
