Rectangular 3D Truss
Detailed view of a rectangular 3D truss structure highlighting joint connections and load distribution analysis.
The image depicts a rectangular 3D truss model, featuring detailed connections between structural members. It showcases how loads are distributed across the truss's framework, emphasizing engineering analysis and joint integrity. The model is designed to analyze forces acting on the truss.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 40 |
| Number of Lines | 89 |
| Number of Members | 89 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.979 tons |
| Dimensions (Metric) | 12.000 x 2.500 x 1.500 m |
| Dimensions (Imperial) | 39.37 x 8.2 x 4.92 feet |
