Rectangular Steel Truss Column
Image showcasing a 3D model of a rectangular truss column structure with multiple beams intersecting at various nodes.
The image displays a 3D structural model of a rectangular truss column with intersecting beams. It illustrates the complexity and interconnection of the structural elements. Each beam connects at specific nodes, forming a comprehensive support system. The design is essential for understanding load distribution in engineering projects.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 40 |
| Number of Lines | 72 |
| Number of Members | 72 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 2.928 tons |
| Dimensions (Metric) | 4.400 x 26.000 x 4.000 m |
| Dimensions (Imperial) | 14.44 x 85.3 x 13.12 feet |
