Windbreak Fabric Panel Analysis
This image shows a detailed analysis of a windbreak fabric panel structure subjected to wind load assessments and stability checks.
The image displays a structural analysis of a windbreak fabric panel, detailing how it responds to environmental forces like wind loads. It highlights computational results related to the panel’s structural integrity and stability. Factors such as tension distribution and supporting elements' performance are evaluated to ensure resilience against wind pressures. This assessment aids in ensuring the durability and safety of the windbreak structure through precise engineering calculations.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 444 |
| Number of Lines | 484 |
| Number of Members | 0 |
| Number of Surfaces | 121 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.061 tons |
| Dimensions (Metric) | 26.400 x 22.800 x 0.000 m |
| Dimensions (Imperial) | 86.61 x 74.8 x 0 feet |
