Concrete Water Tank Design
A detailed image showcasing a concrete water tank modeled with rebar reinforcement, highlighting structural components and stability demonstrations.
The image illustrates a concrete water tank featuring detailed rebar reinforcement. The tank’s structural elements are prominently displayed, showcasing the design considerations required for ensuring stability and durability. This visual serves as an example of advanced modeling techniques applied in concrete construction.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 15 |
| Number of Members | 0 |
| Number of Surfaces | 7 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 40.532 tons |
| Dimensions (Metric) | 8.000 x 9.200 x 8.000 m |
| Dimensions (Imperial) | 26.25 x 30.18 x 26.25 feet |
