Truss Bridge with Cable Stay Design
A truss bridge featuring a cable stay design, illustrating engineering applications.
The image depicts a truss bridge equipped with cable stays, showcasing a combination of structural elements in bridge design. This type of bridge is used to span large distances using both trusses and cables to manage tension and compression effectively. The integration of cable stay technology enhances the load-bearing capacity and reduces materials used compared to traditional designs.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 106 |
| Number of Lines | 305 |
| Number of Members | 305 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 18.286 tons |
| Dimensions (Metric) | 32.000 x 13.000 x 2.539 m |
| Dimensions (Imperial) | 104.99 x 42.65 x 8.33 feet |
