Inflated Pipe
An inflatable pipe model is used to visualize a structure in the construction industry.
The image shows an inflated pipe model used in the construction industry. This structural model illustrates the distribution of pressure and stress along a pipe system. Such models are frequently used to optimize piping systems. The display may have been generated using numerical simulations to better understand the material’s behavior under specific conditions.
Used in
3D Model
Specifications
| Number of Nodes | 9 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 4 |
| Number of Solids | 1 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.358 t |
| Dimensions (Metric) | 4.000 x 10.669 x 4.000 m |
| Dimensions (Imperial) | 13.12 x 35 x 13.12 feet |
