Model 005814 | Column Base with Two Diagonals of Vertical Bracing
The image shows a structural connection of a column with circular hollow sections (CHS) and a base plate. The connection includes two diagonal CHS members welded to the base plate. These elements are anchored in concrete, highlighting the stability of the structure. The welded diagonal connections provide additional support and rigidity for the structural assembly.
3D Model
Specifications
| Number of Nodes | 4 |
| Number of Lines | 3 |
| Number of Members | 3 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 0.075 tons |
| Dimensions (Metric) | 1,400 x 1,000 x 0,000 m |
| Dimensions (Imperial) | 4.59 x 3.28 x 0 feet |
