Parametric Horizontal Bracing Solutions For Towers
Parametric horizontal bracing design for mast and tower construction using advanced engineering software solutions.
The image presents a parametric horizontal bracing model used in the design and stability analysis of masts and towers. The illustration highlights the precise configuration and material specifications within the bracing system offering optimal stability and performance. This structural solution emphasizes flexibility in engineering design through advanced software tools.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 14 |
| Number of Members | 14 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.622 tons |
| Dimensions (Metric) | 5.000 x 0.000 x 5.000 m |
| Dimensions (Imperial) | 16.4 x 0 x 16.4 feet |
