Concrete Building Model
Concrete building model with a rectangular layout, showcasing various floors and bays in X and Y directions without members.
The image illustrates a concrete building model with a rectangular configuration. It features a variable number of bays in both X and Y directions and with different numbers of floors. The model consists only of surfaces without any structural members.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 28 |
| Number of Lines | 32 |
| Number of Members | 0 |
| Number of Surfaces | 10 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 552.000 tons |
| Dimensions (Metric) | 16.000 x 8.000 x 10.000 m |
| Dimensions (Imperial) | 52.49 x 26.25 x 32.81 feet |
