Concrete Staircase with Divided Return Flights
Three-flight concrete staircase featuring divided return flights in a building structure.
The image depicts a concrete staircase with three flights, including divided return flights, providing access between different levels of a structure. This design is often chosen for its functionality and efficient use of space within buildings. The sectioned return flights allow for smooth transitions between each flight, enhancing the stairway's utility in architectural designs.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 14 |
| Number of Lines | 17 |
| Number of Members | 0 |
| Number of Surfaces | 4 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 11.606 tons |
| Dimensions (Metric) | 6.100 x 2.800 x 3.500 m |
| Dimensions (Imperial) | 20.01 x 9.19 x 11.48 feet |
