Timber Fish-Bellied Girders with I-Section
Detailed view of timber fish-bellied girders in linear form with an I-section used in engineering structures.
The image showcases timber girders with a fish-bellied shape, featuring a linear design that incorporates an I-section. These girders are commonly used in engineering structures for their aesthetic appeal and structural efficiency. The fish-belly configuration helps distribute load effectively, optimizing material usage. The design is suitable for various applications, providing both strength and visual elegance.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 30 |
| Number of Lines | 47 |
| Number of Members | 0 |
| Number of Surfaces | 19 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.274 tons |
| Dimensions (Metric) | 7,500 x 1,500 x 0,400 m |
| Dimensions (Imperial) | 24.61 x 4.92 x 1.31 feet |
