Timber Fish-Bellied Girders with I-Section
Parabolic timber fish-bellied girders with an I-section design in a structural model.
Timber girders designed with a fish-bellied configuration exhibit a parabolic shape with an I-section profile. The design highlights the aerodynamic and structural efficiency of the girder's geometry. Such girders are often used to span large distances with reduced material use while maintaining strength and stability. This type of design is visually and structurally optimized for specific load conditions.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 24 |
| Number of Lines | 36 |
| Number of Members | 0 |
| Number of Surfaces | 14 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.293 tons |
| Dimensions (Metric) | 7.500 x 1.500 x 0.400 m |
| Dimensions (Imperial) | 24.61 x 4.92 x 1.31 feet |
