Timber Fish-Bellied Girder
Linear analysis of timber fish-bellied girders showcasing structural behavior and design solutions.
The image focuses on the linear analysis of timber fish-bellied girders, illustrating their structural behavior and design implications. These girders are analyzed for their unique curved shape, which enhances load distribution efficiency. The analysis is crucial in evaluating and optimizing timber structures in construction projects, ensuring safety and performance.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 8 |
| Number of Lines | 12 |
| Number of Members | 0 |
| Number of Surfaces | 6 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.169 tons |
| Dimensions (Metric) | 7.500 x 1.500 x 0.050 m |
| Dimensions (Imperial) | 24.61 x 4.92 x 0.16 feet |
