Steel Silo with Conical Roof
A cylindrical steel silo with a circular base and a conical roof, showcasing engineering design.
The image depicts a steel silo with a circular plan structure and a conical roof. This type of silo is commonly used for bulk material storage, taking advantage of its durable steel construction. The conical roof is designed for efficient runoff and strength. The design highlights structural engineering principles relevant to storage facilities.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 6 |
| Number of Lines | 6 |
| Number of Members | 0 |
| Number of Surfaces | 3 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 72.912 tons |
| Dimensions (Metric) | 11.000 x 6.500 x 11.000 m |
| Dimensions (Imperial) | 36.09 x 21.33 x 36.09 feet |
