Nonagonal Prism with Parametric Design Elements
A digitally modeled nonagonal prism showcasing parametric design capabilities with input variables such as edge count and length.
The image features a nonagonal prism which is digitally modeled to demonstrate parametric design elements. It highlights the use of a JavaScript block that allows changes to the model by adjusting the number of edges, edge length, and the radius of circumscribed or inscribed circles. The model embodies advanced computational design techniques likely used within structural engineering or architecture.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 18 |
| Number of Lines | 27 |
| Number of Members | 0 |
| Number of Surfaces | 11 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 834.546 tons |
| Dimensions (Metric) | 8.507 x 6.000 x 8.638 m |
| Dimensions (Imperial) | 27.91 x 19.69 x 28.34 feet |
