Anticlastic Shell Structures with Hypar Surfaces
Anticlastic shell structures featuring eight straight-edged hypar surfaces arranged over a rectangular plan.
The image features structural systems using anticlastic shell designs with eight straight-edged hypar surfaces. These surfaces are organized over a rectangular layout, highlighting an innovative approach in spatial systems through geometry. The arrangement emphasizes the use of straight edges to define complex surface structures in architectural and engineering applications.
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 13 |
| Number of Lines | 20 |
| Number of Members | 0 |
| Number of Surfaces | 8 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 134.980 tons |
| Dimensions (Metric) | 20.000 x 8.000 x 20.000 m |
| Dimensions (Imperial) | 65.62 x 26.25 x 65.62 feet |
