Basic Layered Solid
Layered solid with specified number of layers, length, width, and thickness for engineering design models.
The image illustrates a layered solid model with definition through the number of layers, length, and width. Each layer's thickness is specified offering detailed design possibilities in engineering. This approach enables flexible creation and adjustment of model structures based on specified parameters. Such models support comprehensive analysis and structural integrity evaluation.
Used in
3D Model
Specifications
| Block parameters editable dynamically | |
| Number of Nodes | 16 |
| Number of Lines | 28 |
| Number of Members | 0 |
| Number of Surfaces | 16 |
| Number of Solids | 3 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 723.200 tons |
| Dimensions (Metric) | 8.000 x 6.000 x 8.000 m |
| Dimensions (Imperial) | 26.25 x 19.69 x 26.25 feet |
