Dialog 'New Combination Wizard'
Dialog box 'New Combination Wizard'
The "New Combination Wizard" dialog box shows the creation of load combination No. 4 with the name "Load combinations | SA3 - Second-order (P-Δ) | Picard". In the "Base" tab, the generation of load combinations for nonlinear calculation is activated. "SA2 - Second-order (P-Δ)" with the Picard iteration method and 100 iterations is selected as the static analysis setting. Under Options I, the consideration of imperfection cases is checked, while stability analysis, initial state, and structure modification are deactivated. In Options II, user-defined action combinations, favorable permanent actions, and a reduction of the generated combinations can be activated.
